STW-500/30 Spray Wash Cabinet


MODEL STW-500/30

Ideal for transmission and automotive repair shops, the STW-500/30 has all the features the professional demands.  Cut-away sides at the bottom of the machine allow engine crane access to the 1,000 lb. Capacity wash turntable for easy loading and unloading. A 12-gauge (0.1046”) heavy-duty steel door and cabinet construction, ease of operation, and all the great features make the STW-500/30 the choice for professionals.


  • Simple Operation
  • 0-60 Minute Automatic Timer
  • Automatic Shut Off
  • Filter for Recycled Solution
  • Friction Drive Turntable
  • Stainless Steel Spray Nozzles
  • Removable Parts Basket
  • Removable Parts Tree
  • Accommodates Engine Crane Loading
  • Gasket Free Door
  • Heavy Duty Polyurethane Casters
  • Oil Skimmer
  • Stainless Steel Pump Impeller
  • 1,000 lb Capacity Heavy Duty Turntable
  • 12 Gauge (0.1046 Inches / 2.65mm) Thickness Steel Door and Cabinet
  • Color in RED


Overall Height66"
Inside Height43"
Inside Width32"
Turntable Diameter30"
Floor Space44" x 43"
Load Capacity1000 lbs.
Water Temperature135º – 175º Degrees F
Pump Output70 psi
Pump Max Flow67 GPM
Electric Heater6 kw
Cycle Timer0 - 60 Minutes
Tank Capacity50 Gallons
Removable Tank ScreenIncluded
Stainless Oil SkimmerIncluded
Small Parts BasketIncluded
Removable Parts TreeIncluded
Stainless Steel HandlesIncluded
Heavy Duty CastersIncluded
Motor3.0HP, 220V AC, 1 Phase
Door12 Gauge (0.1046 inches / 2.65mm) Thickness Steel
Cabinet12 Gauge (0.1046 inches / 2.65mm) Thickness Steel
Shipping Dimension46” x 46” x 73”
Shipping Weight820 lbs.

*Specifications Subject to Change Without Notice

Shipping: Shipped via truck!  If you need faster shipping, please contact us.  Free shipping to commercial areas in 48 continental states.  Local pick up is available.

Additional information

Weight730 lbs
Dimensions46 × 46 × 73 in
