STW-500 Spray Wash Cabinet



2.0 HP Stainless Steel Water Pump.

Warranty: One (1) year parts warranty, five (5) years cabinet warranty

Ideal for transmission and automotive repair shops, the STW-500 has all features the professional demand.

Cut-away sides at the bottom of the machine allow engine crane access to the 1,000 lb capacity wash turntable for easy loading and unloading.

A 12-gauge (0.1046”) heavy-duty steel door and cabinet construction, ease of operation, and all the great features make the STW-500 the choice for professionals.


  • Simple Operation
  • 0-60 Minute Automatic Timer
  • Automatic Shut Off
  • Filter for Recycled Solution
  • Friction Drive Turntable
  • Stainless Steel Spray Nozzles
  • Removable Parts Basket
  • Removable Parts Tree
  • Accommodates Engine Crane Loading
  • Gasket Free Door
  • Heavy Duty Polyurethane Casters
  • Stainless Oil Skimmer
  • Stainless Steel Pump Impeller
  • 1,000 lb. Capacity Heavy Duty Turntable
  • 12 GA (0.1046 inches / 2.65mm) Steel Door and Cabinet
  • Color in Red


Overall Height66"
Inside Height43"
Inside Width32"
Turntable Diameter30"
Floor Space44" x 43"
Load Capacity 1000 lbs.
Water Temperature135º – 175º Degrees F
Pump Output 70 psi
Pump Max Flow54 GPM
Electric Heater6 kw
Cycle Timer0 - 60 Minutes
Tank Capacity50 Gallons
Removable Tank ScreenIncluded
Stainless Oil SkimmerIncluded
Small Parts BasketIncluded
Removable Parts Tree Included
Stainless Steel HandlesIncluded
Heavy Duty Casters Included
Motor2.0HP, 220V AC, 1 Phase
Door12 Gauge (0.1046 inches / 2.65mm) Thickness Steel
Cabinet12 Gauge (0.1046 inches / 2.65mm) Thickness Steel
Shipping Dimension46” x 46” x 73”
Shipping Weight810 lbs.

*Specifications Subject to Change Without Notice

Shipping:  Free LTL shipping to commercial address in 48 continental states.  $60.00 ea. additional charge will be applied on home based business, limited access, and liftgate service. A change of bill of lading charge will be applied if any change occurs after order shipped.

Local pickup is available.  Dock pickup is available.  No additional charge.

Additional information

Weight 730 lbs
Dimensions 46 × 46 × 73 in
